MG-120 2-port RS232/422/485 Modbus Gateway

MG-120 Modbus Gateway FrontMG-120 Modbus Gateway SideMG-120 Modbus Gateway Top
MG-120 Modbus Gateway
MG-120 Modbus Gateway Front
MG-120 Modbus Gateway Side
MG-120 Modbus Gateway Top

MG-120 2-port RS232/422/485 Modbus Gateway

$170.00

MG-120

The MG-120 2-port RS232/422/485 Modbus Gateway supports the standard Modbus Protocol.

  • Serial Port:  2 x DB9 male
  • Serial Standards: RS232, RS422, 4-wire RS485, 2-wire RS485
  • Baud Rate: 50bps to 921Kbps
  • Power Consumption: 5.5W (max.)
  • Operating Temperature: -10° to 60°C
  • TAA Compliant
MG-120

2-Port Modbus Gateway

Standard Modbus TCP/RTU/ASCII Network Integration

PLANET MG-120 2-port RS232/422/485 Modbus Gateway supports the standard Modbus Protocol, which makes it possible for converting any Modbus Protocols between Modbus TCP, Modbus RTU, and Modbus ASCII for all supported hardware interfaces. Its serial protocol can be used for industrial automation where SCADA or HMI system is in place.

Moreover, its network integration can be upgraded from the SNMP network to the automated Modbus TCP network, which brings interconnection over Ethernet longer distances, thus making a network infrastructure more flexible.

A Conversion Bridge for Flexible Network Deployment

The MG-120 can be a conversion bridge between the equipment with the Modbus RTU/ASCII Protocol and the administrator workstations that run the Modbus TCP/IP Protocol. The RS232/422/485 serial interface of the MG-120 provides the Modbus RTU/ASCII operation mode and various baud rate options to meet the demand of integration between the Modbus TCP/IP Protocol, Modbus RTU Master/Slave Protocol and Modbus ASCII Master/Slave Protocol.

MG-120 Application Diagram

The advantage of having the MG-120 is to assist users to build an environment between the Modbus TCP Protocol and the Modbus RTU/ASCII Protocol easily, thus offering an application solution to the control equipment without Ethernet ports, and the control equipment can only control through a PC workstation or control panel.

In addition, the effective integration solution of Modbus Ethernet devices, Modbus serial equipment or multi Modbus master / slave in a hybrid network brings the following:

  • Master mode supports up to 32 TCP slave connection requests
  • Slave mode supports up to 32 TCP master connections

Serial Device vs. Modbus Gateway

Remote Management

The MG-120 makes the connected Modbus RTU/ASCII equipment become IP-based facilities and is able to connect to the Modbus TCP/IP network via its R232/422/485 serial interface and 10/100BASE-TX RJ45 Ethernet port. It provides a remote web management and telnet Interface for efficient remote network management. The MG-120 also provides PLANET Modbus Gateway utility tool and supports PLANET Smart Discovery utility to help network administrator to easily get the current IP subnet address information or change the IP subnet address setting of the MG-120.

MG-120 Remote Management

Modbus Serial Port State Monitoring

The MG-120 shows the details of the total bytes transmitted and received on the RS232/422/485 serial interface, and the detailed total number of frames transmitted and received on the remote web/telnet management interface. This function allows network administrator to check the status and statistics of the MG-120 via the single RS232/422/485 serial interface.
